Key Features:

- Accommodates typical large displays between 50-80” and VESA® up to 1020 - 500 mm, to extend to VESA® 1020 x 600 mm specify FHB7036 bracket for M6 screws, or specify FHB7037 bracket for M8 screws.

- Heavy-duty weight capacity of 310 lbs (140.6 kg)

- Display height adjustment range of 26” (660 mm)

- Interface brackets mount directly to display, then hang on single rail-style cross bracket, eliminating need to remove display from box prior to installation

- Installs into various wall types (wood, concrete, steel, cinder-block)

- Flexible wall assembly anchoring points ensure a minimum of two studs are used - three brackets for 16” on-center studs, or two brackets for 24” on-center studs are included

- Integrated lateral shift allows for easy adjustment left or right

- When installed, mount allows for a minimum of 4” (102mm) clearance from wall

- Plumb adjustment up to 1.5° to compensate for uneven walls

- Telescoping legs allow mount to be adjusted easily around classroom obstacles
